| AM125S 150 | | |
High photoelectric transformation efficiency, high reliability, low weaken, long life;
Advanced PECVD Technology make the dark blue film better distributed;
High quality silver paste results in solar cell contacts of high strength and low series resistance;
Each PV cell is inspected and checked for current reversion, micro cracks, chipping, warping, and any uneven thickness;
AMpv's inspected and checked cells are individually tested and grouped into over 24 performance classes within a tight 2% test accuracy.
AM125S 150 125mm×125mm
Dimension：125mm×125mm±0.5mm;
Diagonal：150mm±1.0mm (round chamfers);
Thickness (Si)：220μm±20μm, 180μm±20μm;
Front：Blue silicon nitride antireflective coatings 1.7mm silver busbar;
Back：Full-surface aluminum back-surface field 3.5mm silver continuous soldering pads. |
 |
| |
 |
|
Efficiency (%)
|
Pmpp(W)
|
Umpp(V)
|
Impp(A)
|
Voc(V)
|
Isc(A)
|
FF(%)
|
|
17.80-18.00
|
2.64
|
0.524
|
5.038
|
0.631
|
5.350
|
78.360
|
|
17.60-17.80
|
2.62
|
0.520
|
5.034
|
0.628
|
5.343
|
77.905
|
|
17.40-17.60
|
2.59
|
0.512
|
5.051
|
0.627
|
5.331
|
77.299
|
|
17.20-17.40
|
2.56
|
0.521
|
4.901
|
0.625
|
5.292
|
77.226
|
|
17.00-17.20
|
2.53
|
0.519
|
4.871
|
0.623
|
5.281
|
76.719
|
|
16.80-17.00
|
2.50
|
0.510
|
4.890
|
0.620
|
5.259
|
76.496
|
|
16.60-16.80
|
2.47
|
0.510
|
4.841
|
0.619
|
5.284
|
75.458
|
|
16.40-16.60
|
2.44
|
0.507
|
4.809
|
0.622
|
5.225
|
75.012
|
|
16.20-16.40
|
2.41
|
0.500
|
4.814
|
0.616
|
5.238
|
74.555
|
|
16.00-16.20
|
2.38
|
0.500
|
4.759
|
0.612
|
5.235
|
74.318
|
|
15.80-16.00
|
2.35
|
0.500
|
4.693
|
0.614
|
5.182
|
73.819
|
