| AM125S 165 | | | AM125S 165 125mm×125mm
Dimension：125mm×125mm±0.5mm
Diagonal：165mm±1.0mm（Round chamfers）
Thickness (Si)：200um±20um，180um±20um
Front：Blue silicon nitride antireflective coatings 1.7mm silver busbar;
Back：Full-surface aluminum back-surface field 3.5mm silver continuous soldering pads.
|
Efficiency(%)
|
Pmpp(W)
|
Umpp(V)
|
Impp(A)
|
Voc(V)
|
Isc(A)
|
FF(%)
|
|
17.80-18.00
|
2.76
|
0.523
|
5.265
|
0.629
|
5.577
|
78.600
|
|
17.60-17.80
|
2.73
|
0.521
|
5.227
|
0.629
|
5.536
|
78.304
|
|
17.40-17.60
|
2.69
|
0.520
|
5.177
|
0.626
|
5.512
|
78.069
|
|
17.20-17.40
|
2.66
|
0.519
|
5.136
|
0.624
|
5.492
|
77.663
|
|
17.00-17.20
|
2.63
|
0.515
|
5.120
|
0.624
|
5.482
|
77.031
|
|
16.80-17.00
|
2.60
|
0.512
|
5.078
|
0.621
|
5.463
|
76.724
|
|
16.60-16.80
|
2.57
|
0.507
|
5.068
|
0.619
|
5.448
|
76.256
|
|
16.40-16.60
|
2.54
|
0.502
|
5.057
|
0.617
|
5.372
|
76.587
|
|
16.20-16.40
|
2.51
|
0.500
|
5.019
|
0.616
|
5.352
|
76.091
|
|
16.00-16.20
|
2.48
|
0.495
|
5.006
|
0.612
|
5.278
|
76.686
|
